Intel® Xeon® processor E3-1200v5 and E3-1200v6 quad core processor family is designed to deliver the best combination of performance, built-in capabilities, and cost-effectiveness. The product also supports Intel® Pentium® and Intel® Core-i3 dual core processors. Choose one of the following processors based on the model:

HPE ProLiant ML30 Gen11 server with one Intel® Xeon® E-2434 Processor, 32 GB (1x32 GB UDIMM) Dual Rank Memory, one HPE MR216i-p Gen11 x16 Lanes without Cache PCI SPDM Plug-in Storage Controller, support for eight SFF drives, one HPE ProLiant ML30 Gen11 Front PCI Fan and Baffle Kit, two HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSDs, two HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kits, and a 3/1/1 warranty

Chipset

Intel® C262 Chipset

What’s New

· Supports latest Intel® Xeon® 6300 processors up to 8 cores 95W TDP

· New HPE Software as a Service (SaaS) management

· New PCIe 5.0 support

· New HPE DDR5 Standard Memory (UDIMM), 4800MT/s maximum speed offering in 16GB and 32GB. Max 128GB memory capacity.

· Embedded 1GbE 4-port NIC with support of PCIe NICs

· New HPE Gen11 Storage Controllers

· New HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device

· New HPE Storage SSD and HDD support

· New HPE iLO 6 support

· HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit

Platform Information

· Form Factor

· 4U Tower

Chassis Types

· 8 SFF hot plug chassis with 2 half-height (5.25") media bays for optional internal slim-line DVD bay kit, RDX4 LFF hot plug chassis with 2 half-height (5.25") media bays for optional internal slim-line DVD bay kit, RDX4 LFF non-hot plug chassis with 2 half-height (5.25") media bays for optional internal slim-line DVD bay kit, RDX

System Fans

· 1 Default system fan module (92 x 32 mm)

· 1 PCIe fan module (92 x 32 mm) depending on model.

Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional information.

HPE Unique Options

HPE ProLiant ML30 Optical Disk Drive Slimline Enablement Kit

P65102-B21

Notes: Required if ODD is selected.

HPE ProLiant ML30 Gen11 Front PCI Fan and Baffle Kit

P65106-B21
